| NO. | ITEM | SPECIFICATIONS | UNIT |
| 1 | Display Mode 显示模式 | EPD | - |
| 2 | Diagonal Size 尺寸 | 3.7 | Inch |
| 3 | Resolution 分辨率 | 240(V)x416(H) | Dots |
| 4 | Active Area 有效显示区域 | 47.04(H) x 81.54(V) | mm |
| 5 | Outline Dimension 外围尺寸 | 53(H) x 92.99(V) | mm |
| 6 | Thickness 厚度 | 1.38±0.3 | mm |
| 7 | Pixel Pitch 像素间距 | 0.196(W) x 0.196(H) | mm |
| 8 | Pixel Size 像素尺寸 | 0.196(W) x 0.196(H) | mm |
| 9 | Display Driver IC 显示驱动 IC | UC8253 | - |
| 10 | Touch Driver IC 触控驱动IC | FT6336 | - |
| 11 | Display Color 显示色彩 | Black/White | Color |
| 12 | Gray Scale 灰阶 | 1 | bit |
| 13 | Brightness 亮度 | cd/m2 | |
| 14 | Contrast Ratio 对比度 | - | |
| 15 | Interface 接口 | 3-wire SPI/4-wire SPI | - |
| 16 | IC Package Type IC 封装类型 | COG | - |
| 17 | Module Connecting Type 模块连接方式 | Connector (Pitch:0.5mm) | - |
| 18 | Weight 重量 | 9.1±0.05 | g |
| 19 | Duty 占空比 | - | |
| 20 | Pins 引脚数 | 24 | Pins |
| 21 | Operating Temperature 操作温度 | 0~50 | ℃ |
| 22 | Storage Temperature 存储温度 | -25~70 | ℃ |
