0.5-inch Monochrome OLED Display (48 × 88 pixels) – Model No. GLO050-D-M2002

Experience crisp, compact visualization with this ultra-thin passive-matrix OLED (PMOLED) display module from Shineworld Innovations Limited. Designed with precision and functionality in mind, this micro-sized display delivers exceptional clarity and efficiency for a wide range of applications.

Key Features:

• A 0.5-inch diagonal screen hosts a resolution of 88 vertical × 48 horizontal pixels, ideal for displaying icons, numeric data, or text in minimal form factor settings.
• Boasts a typical brightness of 230 cd/m² and a minimum contrast ratio of 2000:1, ensuring clear legibility even in varied lighting conditions.
• The module measures 8.93 × 17.1 mm with a thickness of just 1.23 mm, and features a compact active area of 6.124 × 11.244 mm—perfect for sleek and space-conscious electronic designs. Pixel pitch is 0.128 × 0.28 mm.
• Integrated CH1115 controller provides support for I²C interface, smoothly managing display control while minimizing required external components.
• Communication via I²C, with 14 solder-in pins for seamless incorporation into your PCB layout.
• PMOLED technology requires no backlight, offering lightweight simplicity and low power consumption—an ideal choice for wearable devices, health monitors, portable gadgets, and more.


Suggested Application Highlights:

• Compact display for smartbands, fitness trackers, or medical sensors
• Displaying status, alerts, or operational feedback
• Integration into voice recorders, MP3 players, or pen-style devices
• Numeric or icon indicators that demand clarity in constrained spaces
